PORTABLE VERTICAL PANEL SAW SAFETY SPEED

B4309

SAFETY SPEED PORTABLE VERTICAL PANEL SAW

The Safety Speed Portable Vertical Panel Saw is a compact panel saw with a 5’ frame, and a 50” maximum crosscut with a 96” rip cut capacity. Featuring a cut accuracy of 1/32″, and a 1.75″ cut depth.
The Panel Saw replaces the Milwaukee Tool 6480-20 Panel Saw, a private label that Safety Speed Manufacturing made out of their Minnesota factory for Milwaukee Tool for the last 40 years. The Safety Speed Panel Saw includes a 3.25 horsepower Milwaukee Tool motor. The dust collection kit and vacuum for collecting as much dust as possible are optional accessories. This machine is only available within North America.

Features

• Wheels and a folding stand provide portability for your compact panel saw and allow you to move it around your shop as you see fit.
• Standard Equipment
• 3 ¼ Hp, 15 amp industrial, Milwaukee Tool motor.
• Folding Stand
• Wheels
• Zinc plated 1 ¾” steel guide tubes.
• 4 Nylatron roller bearing systems.
• Adjustable vertical and horizontal rulers.
• Quick change from vertical to horizontal cutting.
• Thin material pressure guard.
• Injection-molded plastic material rollers.
• Spring loaded counter balance system.
• Integrated dust collection bonnet.
• Extended warranty.
• TUV certified to UL/CSA standards

Specifications

• Weight 189 lbs
• Dimensions 60 × 11 × 70 in
• Max. Crosscut 50"/1270mm
• Max. Rip Cut 96"/2450mm
• Cut Depth 1 ¾"/45mm
• Cut Accuracy 1/32"/.8mm
• Frame Length 60"/ 525mm
• Saw Blade Diameter 8"/210mm
• Saw Blade Bore Size 5/8"
• Daily Usage 1-3 Hours
• Rollers 8
• Motor volt and amperage 15 amp, 120V, 7.5 amps, 220V
• Motor Manufacturer Milwaukee Tool
• Machine Footprint 15sqft
• Machine Length 60"/1525mm
• Machine Height 75"/1900mm
• Machine Width with stand attached 36"/915mm
