14" DRILL PRESS 3/4HP

CX614

14" Drill Press Craftex CX-Series

This 14" Drill Press is an instant welcome addition to any midsized workshop. This unit features 12 speeds, a powerful 3/4 HP motor, rack and pinion raising mechanism, solid cast iron handles and surface ground cast iron table with rigid columns making this a robust and versatile drill press.
This unit also features laser guided technology, generous sized tilting table with locking levers and coolant trough.

Like all CX-Series machines, this 14" Drill Press features powder coated paint, high quality craftsmanship and a full 3 year warranty.


Specifications
Motor: 3/4 HP, 110V, Single Phase, 9A
Swing: 14"
Spindle travel: 3-1/4"
Speeds: 12 (140, 260, 320, 380, 480, 540, 980, 1160, 1510, 1650, 2180, 3050 RPM)
Spindle: MT2
Drill chuck: 1/64"-5/8"
Drilling Capacity: 3/4" Steel
Table Tilts 90 degrees left and right
Table Swing: 360 degrees
Quill: 66mm
Table: 11 1/4" SQ.
Overall Height: 64"
Weight: 87 kg.
Carton size: 20" x 10" x 56"
3 Year Warranty
